Technical specification
| Capacity:..........................................................................................4000kg |
| Lifting height:..............................................................................1900mm |
| Lifting time:....................................................................................55s |
| Overall width:............................................................................. 3300mm |
| Inside column:............................................................................ 2800mm |
| Voltage:...............................................................................................380v/220v/110v |
| Motor power:..................................................................................2.2kw |
| Rated oil pressure:...................................................................20Mpa |
| Noise:.......................................................................................................≤80dB |
| Machine package size | motor unit package size |
| length........................................2830mm | length..........................................820mm |
| width..........................................450mm | width............................................310mm |
| height.........................................700mm | height...........................................250mm |
| weight.........................................482kg | weight...........................................22kg |
| Total 2 packages Total weight :504kg |
